Stable performance concrete mixing station from China hot sale
Description:
The HZS type mixing station is a simple mixing station with automatic feeding function. The proposed mixing station composed of a combination of a twin-shaft mixer and a batching machine can fully utilize the advantages of the batching machine and the mixer. It is a mandatory and high-efficiency equipment. It can produce a variety of concrete such as plastic and dry-hard concrete. It has high production efficiency and is widely used in large and medium-sized building construction, road and bridge engineering and prefabrication of concrete products. It is an ideal for producing commercial concrete. device. The main engine of the mixing system adopts JS series double-shaft forced mixer. It has good homogeneity of mixing concrete, short mixing time, long life of wearing parts and convenient operation and maintenance. It adopts electronic weighing, computer control and digital design. Display and other control technologies, electronic weighing with buffer device and automatic compensation function, high measurement accuracy. The sand and gravel loading system adopts large-width herringbone belt feeding and has a human walking path, which is an ideal choice for the majority of construction units to produce high quality concrete.
Parameter:
| Model | HZS60 | HZS90 | HZS120 | HZS180 | HZS240 |
| Productivity(m3/h) | 60 | 90 | 120 | 180 | 240 |
| Mixing host | Model | JS1000 | JS1500 | JS2000 | JS3000 | JS4000 |
| Stirring power (kW) | 2×22 | 2×30 | 2×37 | 2×55 | 2×75 |
| Discharge capacity (m3) | 1 | 1.5 | 2 | 3 | 4 |
| Aggregate size (mm) | 60 | 80 | 120 | 150 | 150 |
| Ingredient bin | Warehouse volume (m3) | 3×13 | 3×13 | 3×13 | 4×20 | 4×20 |
| Grid number | 3 | 3 | 3 | 4 | 4 |
| Belt conveyor capacity(t/h) | 200 | 200 | 300 | 400 | 600 |
| Weighing range and accuracy | Aggregate (kg) | 2500±2 | 3500±2 | 4500±2 | 6500±2 | 9000±2 |
| Cement (kg) | 600±1 | 900±1 | 1200±1 | 1800±1 | 2400±1 |
| Fly ash (kg) | 200±1 | 300±1 | 400±1 | 600±1 | 800±1 |
| Water (kg) | 300±1 | 400±1 | 600±1 | 800±1 | 1000±1 |
| Admixture (kg) | 10±1 | 30±1 | 30±1 | 50±1 | 50±1 |
| Total power (kW) | 82 | 108 | 127 | 178 | 220 |
| Discharge height (m) | 3.8 | 3.8 | 3.8 | 3.8 | 3.8 |
Details:
The commercial concrete mixing station consists of a mixing system, an aggregate supply system, a powder storage system, a metering system, a control system and external supporting equipment.
Main types and structure of concrete mixing plant The main types of commercial concrete mixing plant are: HZS60, HZS75, HZS90, double HZS90, HZS120, double HZS120, HZS180, etc. The mixing system of the mixing system is divided into forced mixing according to the mixing mode. And self-propelled stirring. The forced mixer is the mainstream used in mixing stations at home and abroad. It can mix a variety of concretes such as fluidity, semi-dryness and dryness. The self-propelled mixing machine mainly mixes the fluid concrete and is rarely used in the mixing station. The forced mixer is divided into a spindle planetary mixer, a single-shaft mixer and a twin-shaft mixer according to the structure. Among them, the comprehensive performance of the twin-shaft forced mixer is good.
Advantages:
1. Easy to install and disassemble, the foundation can be installed properly and flat, and the installation period is short, which is convenient for frequent movement.
2. When transporting, the height and width of the cement silo are not exceeded. A 6-meter car can be transported, and the cement silo can be superimposed and recycled.
3. The overall height after installation is low, and the overall length is suitable for the storage of various bulk materials such as cement, fly ash and bentonite in the corridor.
4. The cement is blown into the storage bin by the wind through the feeding pipe. As the pressure in the bin increases, the gas in the bin is filtered by the dust removing device and discharged from the air outlet, and the mixed cement in the gas is left to the cement silo, which is easy to operate. And no pollution to the environment.
Work site:
